1X4 LAN WDM DEVICE

LAN WDM utilizes free space technology, with ultra-compact size and high reliability. It can be widely used in 40Gbps or 100Gbps application. All Profiber’s WDM products are Telcordia GR-1209 and GR-1221 compliance.

  • • Low Insertion Loss

    • High Stability and reliability

    • High Channel Isolation

    • Ultra compact size

    • Epoxy-free on Optical Path

  • CHANNEL WAVELENGTH:
    CH1, UNIT: nm, PARAMETER: 1294.53-1296.59
    CH2, UNIT: nm, PARAMETER: 1299.02-1301.09
    CH3, UNIT: nm, PARAMETER: 1303.54-1305.63
    CH4, UNIT: nm, PARAMETER: 1308.09-1310.19

    WAVELENGTH RANGE:
    UNIT:     nm, PARAMETER: 1280-1330

    CHANNEL SPACING: UNIT: GHz, PARAMETER: 800

    INSERTION LOSS:
    UNIT:     dB, PARAMETER: ≤1.5

    ISOLATION:
    ADJACENT, UNIT: dB, PARAMETER: ≥25
    NON-ADJACENT, UNIT: dB, PARAMETER: ≥35

    CHANNEL RIPPLE: UNIT: dB, PARAMETER: ≤0.5

    POLARIZATION DEPENDENT LOSS: UNIT: dB, PARAMETER: ≤0.5

    TDL: UNIT: dB, PARAMETER: ≤0.5

    UNIFORMITY: UNIT: dB, PARAMETER: ≤1.0

    POLARIZATION MODE DISPERSION: UNIT: ps, PARAMETER: ≤0.2

    RETURN LOSS: UNIT: dB, PARAMETER: ≥45

    DIRECTIVITY: UNIT: dB, PARAMETER: ≥50

    MAXIMUM POWER HANDLING: UNIT: dB, PARAMETER: ≤300

    OPERATING TEMPERATURE: UNIT: ℃, PARAMETER: -5～70

    STORAGE TEMPERATURE: UNIT: ℃, PARAMETER: -40～85

    PACKING: UNIT: mm, PARAMETER: 21x13x6.5

  • • WDM Network

    • CFP transceivers

    • Data communicaton

    • 40G or 100G applications
